当前位置：长春市亮丽光电有限公司>>激光器>> LL545-20mw545nm激光器
| 产地 | 国产 | 工作状态 | 连续激光器 |
|---|---|---|---|
| 激光器波长 | 545nm | 激励方式 | 光泵浦 |
| 冷却方式 | 风冷 | 售后保修期 | 12个月 |
545nm激光器
LL-FN-543
LD PUMPED ALL-SOLID-STATE GREEN LASER AT 545nm All solid state 545nm green laser is made features of high output power stability, good beam profile, ultra compact, long lifetime, low cost and easy operating, which is widely used in collimation, laser medical treatment, scientific experiment, optical instrument, etc.
| Part number | LL-FN-543 |
| Wavelength (nm) | 543± 1 |
| Operating mode | CW |
| Output power (mW) | 1-1000 |
| Power stability (rms, over 4 hours) | <3%, <2%, < 1% |
| Transverse mode | Near TEM00 |
| M2 factor | < 1.2 |
| Beam diameter at the aperture ( 1/e2, mm) | <2.0 |
| Beam divergence, full angle (mrad) | < 1.5 |
| Polarization Ratio | > 100:1, (Horizontal or Vertical Optional) |
| Warm-up time (minutes) | <5 |
| Pointing stability after warm-up (mrad) | <0.05 |
| Beam height from base plate (mm) | 27.4 |
| Operating Temperature (°C) | 10-35 |
| Modulation option | TTL on/off, 1Hz- 1kHz, 1kHz- 10kHz, |
| Power supply (90-264VAC) | PSU-H-LED/ |
| Expected lifetime (hours) | 10000 |
| Warranty | 1 year |
